pi-zep

A pi extension that books project times (Projektzeiten) in ZEP over plain HTTP — no browser, and no paid ZEP REST API.

Why

ZEP's official REST API is a paid add-on and, at least up to ZEP v7.13.88, cannot create a Projektzeit booking at all. The web UI itself talks to a plain PHP endpoint that can, and it needs no API key. This extension speaks that endpoint directly.

How it works

The whole protocol was reverse-engineered from the web client. Three parts:

{root} is <baseUrl>/<mandant>, e.g. https://zep-online.de/zepneoimpulse.

The booking request needs:

• the x-requesttoken header (mandatory), plus requesttoken in the body,
• the PHPSESSID cookie and the CLIENTSESSID query parameter — neither alone is accepted,
• a form-urlencoded body with datum, von, bis, dauer, projektId, vorgangId, taetigkeit, bemerkung, ort, …

Three things that bite

1. The token rotates. Every response — including errors — hands out the next requesttoken. This client adopts it automatically. Reusing an old token is not merely rejected: it makes the server log the session out (msg=555001 / 555003 / 555009) and you have to log in again.
2. Never send an ajax call without a token. The client fetches the page first when it does not hold a fresh token, so it can never fall into (1).
3. ZEP locks the account after 5 failed password attempts. The client therefore caches the session in ~/.pi/zep-session.json and only logs in again when the cached session stops working. A failed login reports the remaining attempts (noch=N).

Reads and deletes use the same envelope:

GET …/ajax.php?…&mgr=ProjektzeitMgr&mgrId=0&action=setKw&kwDate=<monday>   # week overview
GET …/ajax.php?…&mgr=ProjektzeitMgr&mgrId=0&action=delete&objectId=<id>&kwDate=<monday>&userId=<user>
POST …/ajax.php?…&mgrId=3&action=save&formrefresh=true&formrefreshtrigger=projektId  # re-render the form for another project

The last one is the UI's own mechanism for changing the project: the Vorgang list is rendered server-side, so it only contains the Vorgänge of the project the page was rendered for. Posting formrefresh=true returns the new <select id="vorgangId"> without saving anything.

Capacity planning ("Einplanung")

Same ajax.php, different page context. The plan page has no table — the numbers live in an ApexCharts options object inside the snippet:

var optionschart123 = {"series":[
  {"name":"Verfügbarkeit [108,80 h]","type":"area","data":[6.4,6.4,0, …]},
  {"name":"K-10000-00003 (…) [54,40 h]","type":"bar","data":[3.2,3.2,0, …]},
  {"name":"gesamt [82,40 h]","type":"line","data":[4.8,4.8,0, …]}],
 "xaxis":{"categories":["Heute","Morgen","19.09.", …]},
 "title":{"text":"<employee>"},"subtitle":{"text":"17.09.2026-17.10.2026"}}

• Read: POST ajax.php?…&pageContextId=Einplanung&mgr=MeineEinplanungMgr&mgrId=0&action=filter with the filter form (von, bis, von_bisquicklinkdata, projektEinplanung, gestapelt, ff_projektprojektTyp, scale, Ausführen).
• The object is JavaScript, not JSON: axis locales reference a page global ("locales":[apex_lang_de]) and axis/tooltip formatters are real function expressions. Both must be neutralised before JSON.parse — extractChartOptions() replaces function bodies and bare identifiers with null.
• Series kinds are detected on the name prefix (Verfügbarkeit, gesamt, else project) and only fall back to the chart type. Project totals are read from the [54,40 h] suffix in the series name; the per-day values come from the data array.
• Write: POST …&mgr=MeineEinplanungMgr&mgrId=0_0_0_1&action=edit&refresh=1 with edited=[{p:<projektId>,d:<YYYY-MM-DD>,e:<wert|null>,a:'h'|'%',b:<bemerkung>}] plus selected, scrollLeft and einplanungAuchAnNichtArbeitstagen. Only the cells the grid marked as edited are sent, so a save merges into the existing plan instead of replacing it; e:null clears a cell.
• A plan cell is either hours (a:'h') or a percentage of that day's availability (a:'%') — 25 % of a 6,40 h day is 1,60 h, which is how a percentage shows up in the chart.
• Grid markup: <td class="pep pepdata at pm <date>" data-datum data-einplanung data-einplanungart data-bemerkung data-stundensatz>. Rows are the projects (tr[data-projektid]), the grid is keyboard driven (digits, % suffix, Enter = save, Delete = clear).

Response shapes (verified against the live server)

A rejection does not arrive in javascript. It arrives as a schnipsel whose target is a form message slot:

<div class="card-alert alert alert-danger">
  <div class="alert-message">Projektzeit Do, 17.09.2026, 08:00 - 08:15 Speichern
  fehlgeschlagen. Diese Zeit kann nicht gebucht werden, da dadurch die Plan
  Stunden des Projekts/Vorgangs überschritten würden. Projektleiter wurden ggf.
  per E-Mail informiert.</div>
</div>

A client that only inspects javascript would report a useless "unspecified error" here. extractSnippetAlert() reads the real text.

Other message texts observed:

• … Tätigkeit co bei Vorgang 90-02 nicht erlaubt. — the activity is not allowed for that Vorgang (90-02 only accepts co_nb).
• … Plan Stunden des Projekts/Vorgangs überschritten… — the Vorgang's planned hours are used up.

Week table quirks

• The setKw snippet carries no target — it has to be recognised by content (pz_kwnav, id="objectId…", class="tag_…"), never by target.
• The save response ships a calendar snippet targeting managerdiv_ProjektzeitMgr, which must not be mistaken for the week table.
• The ISO date of a day row is in id="day_YYYY-MM-DD" (fallback: the openMahlzeiten(this, 'YYYY-MM-DD') onclick, then the weekday + DD.MM. label).
• A day row's label is split across <div>Do</div><div>17.09.</div>, so plain innerText yields Do17.09. while tag-stripping yields Do 17.09. — parse the latter.
• The first booking of a day is rendered inside the day row itself — its label cell carries rowspan, so that row holds 12–13 cells. Further bookings of the same day follow as standalone rows, separated by a class="luecke" spacer (1 cell). A parser that only knows standalone rows silently drops the day's first booking and attaches the remaining ones to the previous day.
• Booking columns are therefore read relative to the von cell: von, bis, Dauer, ·, Projekt, Vorgang, Tät., fakturierbar, Bemerkung[, Ort].
• The optional last cell is the Ort (place of work). It carries no data-columnid of its own and ZEP renders it only when there is something to report; a trailing * marks a deviation from the default, and a missing cell means NULL (Erste Tätigkeitsstätte).

Tools

Usage

zep_setup  name=work userid=patrick.weppelmann password=… mandant=zepneoimpulse
zep_status probe=true
zep_projects projekt=Contoso
zep_week
zep_book   datum=2026-09-17 von=08:00 bis=12:00 projekt=413 vorgang=90-01 taetigkeit=co bemerkung="4711 Beispiel-Ticket"
zep_book   datum=2026-09-17 entries=[{von:"08:00",bis:"12:00",bemerkung:"…"},{von:"13:00",bis:"17:00",bemerkung:"…"}]

projekt and vorgang accept either an id (413, 3284) or part of the label (Contoso, 90-01). A full example, dryRun first:

zep_book projekt=Contoso vorgang=90-01 datum=2026-09-17 von=08:00 bis=12:00 dryRun=true

Important behaviour

• ZEP rejects rather than overwrites. A booking that would exceed the Vorgang's planned hours comes back as "Diese Zeit kann nicht gebucht werden, da dadurch die Plan Stunden des Projekts/Vorgangs überschritten würden. Projektleiter wurden ggf. per E-Mail informiert." This extension reports that text verbatim and never silently retries on another Vorgang.
• fakturierbar is derived server-side from project + Vorgang + Tätigkeit. The field is disabled in the UI and is deliberately not sent.
• jpeg-free, dependency-light: the only runtime dependency is typebox.

Verified live

The full write cycle was exercised against the real system on 2026-09-17: form re-render for another project, a booking created and confirmed in the week table, then deleted and confirmed gone. A rejected booking (plan hours exhausted) and a rejected Tätigkeit were reproduced as well.

The capacity planning was exercised the same day: the Einplanung chart was read (read path) and a matrix cell was written and read back (zep_plan_set).

What is not covered by that test run: a successful password login, because that requires the account password. The endpoint, the field names and the failure contract (302 → login.php?…&action=login&msg=1&noch=N) were verified with throwaway credentials; everything after the redirect was verified with a real session.

Files

index.ts                    extension entry point (tool registration)
src/types.ts                plain data shapes
src/config.ts               profile + session persistence (~/.pi, mode 0600)
src/clients/zep-client.ts   HTTP session handling, booking, week, delete
src/clients/zep-parse.ts    tolerant parsers for ZEP's HTML / ajax JSON
src/formatting/             domain data -> text
src/tools/                  one tool per file
tests/                      parser + wire-contract tests (stubbed fetch)

Development

npm install
npm test        # node --test
npx tsc --noEmit

The wire contract is pinned by tests/zep-client.test.ts, which asserts the exact query parameters, headers and body fields against the live system's observed behaviour.

Configuration files

Both are written with mode 0600.
