@siva-sub/pi-docparser

A standalone Pi package that adds local document-understanding tools plus a companion parse-document skill for AI agents.

This fork extends the original maxedapps/pi-docparser package with LiteParse complexity detection and optional model-configurable visual understanding. Core parsing remains local by default. Visual analysis is opt-in, and remote model calls require explicit allowCloud: true.

What this package provides

Extension tools

This package registers five tools:

Tool	Purpose
document_parse	Parse a local document to text or json, save the full result to a temp file, and optionally render screenshots.
document_search	Search a local document for a phrase and return page numbers plus bounding boxes for each hit.
document_screenshot	Render document pages as PNG images, return image blocks for direct model inspection, and save PNG files to a temp folder.
document_complexity	Inspect per-page complexity signals (images, vector area, OCR needs) and identify visual-candidate pages for vision analysis.
document_visual_analyze	Render candidate pages and analyze screenshots with the active Pi vision model or an explicit OpenAI-compatible endpoint. Requires explicit cloud permission for remote targets.

Use document_parse for extraction, document_search for citations/source locations, document_screenshot when visual layout, charts, signatures, dense tables, or page appearance matter, document_complexity to find pages that carry significant non-textual content, and document_visual_analyze to interpret charts and diagrams with a vision model.

Skill

Ships a parse-document skill that teaches agents to:

• prefer document_parse over raw lit CLI commands
• choose text vs JSON output deliberately
• search before screenshotting when looking for known text
• use screenshots only when visual inspection is useful
• keep large parsed outputs out of context until needed

LiteParse v2 behavior

LiteParse v2 is a Rust rewrite using PDFium for text extraction/rendering and native Tesseract for OCR. Compared with v1, it is substantially faster and exposes a simpler Node API:

const result = await parser.parse("document.pdf");
// result = { pages: ParsedPage[], text: string }

const screenshots = await parser.screenshot("document.pdf", [1, 2]);

JSON output from document_parse is the full LiteParse v2 parse result:

{
  "pages": [
    {
      "pageNum": 1,
      "width": 612,
      "height": 792,
      "text": "...",
      "textItems": [{ "text": "Revenue", "x": 72, "y": 120, "width": 48, "height": 12 }]
    }
  ],
  "text": "..."
}

Removed LiteParse v1 options are not supported:

• preciseBoundingBox
• preserveLayoutAlignmentAcrossPages

Alternatives for agents: use JSON textItems bounding boxes, document_search, document_screenshot, or narrower targetPages.

Supported inputs

This package uses LiteParse and supports the formats LiteParse supports locally, including:

• PDF
• DOC / DOCX / DOCM / ODT / RTF / Pages
• PPT / PPTX / PPTM / ODP / Keynote
• XLS / XLSX / XLSM / ODS / CSV / TSV / Numbers
• PNG / JPG / JPEG / GIF / BMP / TIFF / WebP / SVG

Support for non-PDF formats may depend on host tools such as LibreOffice or ImageMagick. See Host dependencies.

Requirements

• pi installed and working
• Node.js 20.6+
• local machine access to the files you want to parse

Installation

pi install npm:@siva-sub/pi-docparser

Or from GitHub:

pi install git:github.com/siva-sub/pi-docparser@main

Example model tool calls

These are representative tool calls pi may make internally.

Extract plain text

document_parse({
  path: "./docs/contract.pdf"
})

Useful for summarizing, quoting, reviewing, or answering questions where layout coordinates are not needed.

Extract JSON with bounding boxes

document_parse({
  path: "./reports/financial-report.pdf",
  format: "json",
  targetPages: "1-3"
})

Useful when an agent needs page structure, text coordinates, or bounding boxes.

Search for a phrase and get source locations

document_search({
  path: "./reports/financial-report.pdf",
  phrase: "Revenue grew",
  targetPages: "1-10"
})

Returns each hit with page number and bounding box, useful for citations and deciding which pages to screenshot.

Render pages for visual inspection

document_screenshot({
  path: "./reports/financial-report.pdf",
  pages: "4",
  dpi: 150
})

Useful for charts, figures, signatures, dense tables, and cases where extracted text is insufficient.

Find visual-candidate pages

document_complexity({
  path: "./reports/financial-report.pdf"
})

Returns per-page complexity signals and a visual-candidate score. Pages with significant images, vector graphics, or full-page scans are flagged as candidates for vision analysis. This tool does NOT identify diagram type, only flags pages worth looking at.

Analyze charts and diagrams with a vision model

document_visual_analyze({
  path: "./reports/financial-report.pdf",
  pages: "3,7,12",
  focus: "bar chart trends",
  baseUrl: "http://127.0.0.1:11434/v1",
  model: "qwen2.5vl:7b",
  allowCloud: false
})

Renders the selected pages as screenshots and sends them to the active Pi image-capable model through Pi's provider-agnostic SDK, or to an explicit OpenAI-compatible endpoint. The model returns diagram type, title, axes, observations, nodes/edges (for flowcharts), and uncertainties. Findings are model-inferred descriptions with provenance, separate from LiteParse text coordinates.

The model and endpoint are configurable via environment variables or per-call parameters. When no explicit endpoint is supplied, the active Pi model selected with /model, --model, or settings is routed through Pi's provider-agnostic SDK. Inspect available models with pi --list-models, then select one such as pi --model openai-codex/gpt-5.4-mini or use /model in an interactive session. Loopback URLs (Ollama, vLLM, LM Studio) work without cloud permission, except for explicitly cloud-routed model IDs such as *:cloud. Remote endpoints require allowCloud: true.

Parse a password-protected document

document_parse({
  path: "./docs/protected.pdf",
  password: "user-provided-password"
})

Use offline/custom OCR data

document_parse({
  path: "./scans/report.pdf",
  ocr: "auto",
  ocrLanguage: "eng",
  tessdataPath: "/path/to/tessdata"
})

tessdataPath points LiteParse/Tesseract at local .traineddata files. Most users do not need it; it is useful for air-gapped environments or custom language packs.

Tool behavior notes

document_parse

• Saves full parsed output to a temporary .txt or .json file.
• Returns a short preview to avoid flooding model context.
• Supports targetPages, OCR options, password, tessdataPath, and optional screenshotPages.
• Defaults maxPages to LiteParse v2's default: 1000.

document_search

• Parses the document and searches page textItems with LiteParse's searchItems helper.
• Returns structured hits with pageNum, text, x, y, width, height, and optional confidence/font data.
• Use before screenshotting when searching for known text.

document_screenshot

• Renders pages as PNG screenshots.
• Returns image content blocks the model can inspect directly.
• Also saves screenshots to temporary files and returns their paths.
• Can render supported non-PDF documents when required host conversion tools are installed.

document_complexity

• Uses LiteParse's isComplex() API to inspect each page without a full parse.
• Returns per-page signals: text coverage, image block count, image coverage, vector area, garbled text, and OCR needs.
• Adds a heuristic visual-candidate score (0-1) combining image and vector signals using a noisy-OR combination.
• Pages at or above the threshold (default 0.4) are flagged as visual candidates for document_visual_analyze.
• The score is heuristic: a high score means the page carries significant non-textual content, not that a specific chart type is present.

document_visual_analyze

• Renders selected (or auto-selected) pages as screenshots at a configurable DPI.
• Sends images to the active Pi image-capable model through Pi's SDK when no explicit endpoint is configured, or to an OpenAI-compatible vision model for explicit endpoints.
• Returns structured findings: diagram type, title, axes, observations, nodes/edges, annotations, uncertainties, and confidence.
• Defaults to local-only: requires allowCloud: true for remote or cloud-routed models, even through a loopback proxy.
• Model and endpoint are configurable via environment variables (PI_DOCPARSER_VISUAL_BASE_URL, PI_DOCPARSER_VISUAL_MODEL, PI_DOCPARSER_VISUAL_API_KEY, PI_DOCPARSER_ALLOW_CLOUD, PI_DOCPARSER_VISUAL_DPI) or per-call parameters.
• Findings are model-inferred with provenance metadata. They are NOT citation geometry. Pair with document_search for text-level citations.

OCR notes

LiteParse v2 uses built-in native Tesseract OCR by default when OCR is enabled and no ocrServerUrl is provided.

Important details:

• OCR is selective: LiteParse OCRs text-sparse pages or image regions rather than blindly OCRing everything.
• Built-in Tesseract typically uses ISO 639-3 language codes such as eng, deu, fra, jpn.
• Many HTTP OCR servers instead expect ISO 639-1 codes such as en, de, fr, ja.
• ocrLanguages is joined into a multilingual language string for built-in Tesseract.
• When ocrServerUrl is used, only the first entry from ocrLanguages is forwarded.
• For offline/custom OCR data, use tessdataPath or set TESSDATA_PREFIX.

Host dependencies

This package relies on LiteParse for local parsing and conversion. Depending on the input format, you may need additional host tools installed.

The tools perform lightweight preflight checks for the most common host dependencies and also forward LiteParse's original error messages when conversion fails.

LibreOffice

Needed for many Office document, presentation, and spreadsheet conversion paths.

# macOS
brew install --cask libreoffice

# Ubuntu / Debian
apt-get install libreoffice

# Windows
choco install libreoffice-fresh

ImageMagick

Needed for image-to-PDF conversion paths.

# macOS
brew install imagemagick

# Ubuntu / Debian
apt-get install imagemagick

# Windows
choco install imagemagick.app

Doctor command

If parsing fails because a host dependency is missing, the extension points users to:

/docparser:doctor

Run it inside pi to:

• detect the current operating system
• check whether LibreOffice and ImageMagick are available
• optionally focus the check on a specific file path
• suggest install commands for the current machine
• optionally attempt those install commands after user confirmation when that looks safe to automate

Examples:

/docparser:doctor
/docparser:doctor @./slides.pptx

Known limitations

• OCR quality depends on scan quality, page layout, and the chosen OCR language.
• Some conversion paths depend on external host tools.
• Full parse and screenshot outputs are written to temporary files by default, not directly into your repository.
• Native LiteParse v2 npm packages are platform-specific; unsupported platforms may need upstream LiteParse support first.

Third-party dependency: LiteParse

This package depends on:

• @llamaindex/liteparse
• license: Apache-2.0
• purpose: local document parsing, OCR, screenshots, search, and conversion support

LiteParse itself documents its own upstream dependencies and platform requirements. See:

• repository: https://github.com/run-llama/liteparse
• npm package: https://www.npmjs.com/package/@llamaindex/liteparse
• docs: https://developers.llamaindex.ai/liteparse/

Additional attribution details are listed in THIRD_PARTY_NOTICES.md.

Changelog

See CHANGELOG.md.

License

This package is licensed under the MIT License. See LICENSE.
