pi-submarine 🥽

pi-submarine is a minimal Pi extension for delegating tasks to child Pi sessions, also known as subagents. The parent receives compact run metadata, the child session ID, and the child's final answer.

The diagram shows the delegation model: each subagent() call runs one focused child Pi session, calls in the same turn run in parallel, and each call returns a compact result without the child transcript.

Features

• Fresh child sessions for isolated work, or forked child sessions when the child should inherit the current conversation branch.
• Named agents defined by simple markdown files with five frontmatter knobs: description, model, thinkingLevel, agentsMd, and skills.
• Per-agent model and thinking-level defaults with optional model and thinking-level overrides on each subagent call.
• Agent discovery for user-level and project-level markdown agents, including subagent_list for showing what is visible from a cwd.
• Runtime status updates that report activity, turn counts, nested children, and context usage.
• An append-only <parent-session>.jsonl.subagents.md activity log that can be tailed while children run.
• Nested subagents, with a depth limit to prevent accidental circular delegation.
• Support for parallel subagents through Pi's native multi tool calling.
• Resumable child sessions through subagent_resume when continuing the same child context is useful after an abort, failure, or deliberate follow-up.

The package is deliberately narrow: one subagent call runs one foreground child Pi session and waits for it. It does not provide built-in agent roles, background jobs, chains, dashboards, or a workflow engine.

Usage

The extension registers three tools:

subagent({ agent?, task, model?, thinkingLevel?, context?, cwd? })
subagent_resume({ sessionId, message })
subagent_list({ cwd? })

All three tools use strict parameter schemas: unknown properties are rejected.

[!IMPORTANT] pi-submarine treats project-local Pi inputs for the child cwd as trusted. Review unfamiliar .pi/ and .agents/ files before running subagents.

The common calls are intentionally small:

subagent({ task: "Inspect src/runner.ts and summarize the control flow." })
subagent({ agent: "vision", task: "Read any screenshots or images and return their contents", model: "glm-5v-turbo" })
subagent({ context: "fork", task: "Use the current conversation branch to check my last plan." })

Fresh runs are independent child sessions. They can use files and tools in their cwd, but they do not see the current parent conversation, so put the needed background, paths, constraints, and desired output in task. Fresh calls do not forward images attached to the parent turn; include child-readable image paths in task. Use context: "fork" only when the child should inherit a copy of the current conversation, including images already present on that branch.

subagent({ agent?, task, model?, thinkingLevel?, context?, cwd? })

Runs one focused task in a child Pi session and returns compact session metadata plus the child's final answer.

Arguments:

• task is required. It is the prompt for the child session.
• agent is optional. Omit it for the generic default mode. Pass a filename stem such as "vision" to use a markdown agent named vision.md. A literal agent: "subagent" means the markdown file subagent.md; omission is the only way to request the default mode, although a literal agent: "default" is tolerated and resolves to the default mode whenever no default.md is visible.
• model is optional. Pass a model ID such as "glm-5v-turbo" or a canonical provider/model-id reference. It overrides the named agent's frontmatter model for this call.
• thinkingLevel is optional. Pass one of Pi's thinking levels (off, minimal, low, medium, high, xhigh, max). It overrides the named agent's frontmatter level for this call.
• context is optional and defaults to "fresh". Use "fresh" for a new child session. Use "fork" only when the child must inherit the current conversation branch.
• cwd is optional and valid only with fresh runs. Usually omit it; the child then uses the caller cwd. Set it only when another directory should be the child's workspace/project: relative tool paths and bash run there, and project-agent discovery, context files such as AGENTS.md / CLAUDE.md, skills, and Pi resources follow that cwd. Relative cwd values resolve from the caller cwd.

Model references must match Pi's current model catalog and have configured authentication. For a bare model ID, pi-submarine first prefers a matching model from the parent's provider, then the only authenticated match; otherwise it asks for a canonical reference. If neither the call nor the agent chooses a model, fresh runs inherit the parent model and fork runs restore the model from the copied branch. An explicit thinking level must be supported by the resolved model: if it is not, the run fails before child artifacts are created and the error lists the supported levels rather than silently clamping. When no level is requested, fresh runs use Pi's default for the model and fork runs restore the level recorded on the copied branch.

Fresh runs create a new child session below the current root session's .subagents/ directory; nested subagents share that directory. The tail-able Markdown activity log is the sibling <parent-session>.jsonl.subagents.md file. Fork runs branch from the current conversation leaf into the same .subagents/ directory.

If a named agent cannot be found from an explicit cwd but would have been found from the caller cwd, subagent fails with a hint to omit cwd and put external paths in task instead.

A successful result looks like this:

## Subagent vision result
Subagent session ID: 019...

<child assistant answer>

Use the Subagent session ID for later continuation.

subagent_resume({ sessionId, message })

Continues an existing child Pi session in the current parent/root session. It requires a persisted parent Pi session so it can find the current parent/root manifest. It reopens the recorded child JSONL session, appends message, waits for the next child answer, and returns the same compact result shape.

Arguments:

• sessionId is required. Use the child Pi session ID from an earlier subagent or subagent_resume result, or from recovery text after an interrupted or failed child run.
• message is required. It is appended to that same child conversation.

Resume lookup is scoped to the current parent/root manifest. It does not search globally, fork, or copy the child session. Use subagent for unrelated work; use subagent_resume when continuing the same child context is clearer than starting over.

For original fresh runs, resume reloads current prompt resources from the recorded cwd, including named-agent agentsMd and skills controls. For original fork runs, resume uses fork-style resources. All resume calls send message as plain user text, because the initial subagent prompt envelope is already in the child transcript.

subagent_list({ cwd? })

Lists the markdown agents visible from a working directory, plus the special default mode where agent is omitted.

Arguments:

• cwd is optional. Usually omit it to inspect the caller project context. An explicit cwd is an advanced override for listing another directory's visible agents; relative paths resolve from the caller cwd.

The text result shows each markdown agent's name, source label (user or project), description, and path, plus a Callable models section listing one line per model with configured authentication and its supported thinking levels, marking the current session model. The structured details include the resolved cwd, source counts, user/project agent directories, the callable model catalog, and the current model. If an explicit cwd hides project agents visible from the caller cwd, the result includes a warning.

Markdown agents

Markdown agents are prompt resources. Treat them like trusted code: review project .pi/agents/*.md files before running subagents in an unfamiliar checkout.

User agents live under the Pi agent directory in agents/*.md ($PI_CODING_AGENT_DIR/agents when that environment variable is set, otherwise Pi's normal agent directory). Project agents live in the nearest ancestor .pi/agents/*.md from the effective cwd. Project agents override user agents with the same filename stem.

For project agents, normally pass the agent name and omit cwd. For example, create .pi/agents/vision.md:

---
description: Reads screenshots, diagrams, and other images.
model: glm-5v-turbo
thinkingLevel: low
agentsMd: auto
skills: none
---

Read every image path named in the task. If no path is given, find the
relevant image files in the cwd first. Return visible text and a concise
description, separating direct observations from inferences.

The frontmatter model is the default:

subagent({ agent: "vision", task: "Read screenshots/login.png and return its contents." })

A call-level model selects or overrides it for one invocation:

subagent({ agent: "vision", task: "Read any screenshots or images and return their contents", model: "glm-5v-turbo" })

If the task needs files outside the project, put those paths in task unless you intentionally want the external directory to define the child's project context.

Agent files use the small frontmatter block shown above, not YAML. description is required. model is optional and uses the same model reference rules as the call-level argument. thinkingLevel is optional and may be one of off, minimal, low, medium, high, xhigh, or max; it uses the same call-level override and validation rules as model. agentsMd is optional and may be none or auto; it defaults to none. skills is optional and may be auto, none, or a comma-separated list of skill names; it defaults to auto. Unknown keys, blank frontmatter lines, comments, quoted values, arrays, block scalars, duplicate keys, missing delimiters, and empty bodies are rejected.

Discovery is non-recursive and ignores hidden files, nested directories, uppercase .MD, and *.chain.md files.

Every initial subagent call sends the child a single XML-style user prompt envelope with subagent context and the task. Named agents add a sanitized <name-agent> block containing the markdown body between that context and the task. Fresh default-mode runs do not load markdown agents, suppress AGENTS.md / CLAUDE.md context files, and keep normal skills. For named fresh runs, agentsMd controls context-file loading and skills controls skill loading; the agent body stays in the user prompt envelope rather than the child system prompt. Fork runs ignore those frontmatter resource controls but use the same user prompt envelope for omitted and named agents. A frontmatter model or thinking level applies to both fresh and forked initial runs. Resuming restores the model and thinking level recorded in the child session rather than reapplying the current agent-file defaults.

Artifacts and progress

subagent and subagent_resume require a persisted parent Pi session. Once a child episode starts, pi-submarine writes artifacts beside the root parent session when possible, even if the episode later fails or is aborted:

<parent-session>.jsonl
<parent-session>.jsonl.subagents.md
<parent-session>.jsonl.subagents/
  manifest.jsonl
  <child-session>.jsonl

manifest.jsonl records lifecycle data used for resume and nesting. <parent-session>.jsonl.subagents.md is an append-only status stream suitable for tail -f, not a transcript. Full child messages remain in the child session JSONL.

While a child runs, Pi frontends receive portable text partial updates like this:

Log: ~/.pi/agent/sessions/.../parent.jsonl.subagents.md
- subagent (6% ctx, 1 turn) -> vision (? ctx, 2 turns): using read

The same update includes structured details.run data:

type SubagentRunView = {
  episodeId: string
  sessionId: string
  agent: string
  status: "running" | "completed" | "failed" | "aborted"
  turnCount: number
  lastActivityAt: string
  activity: string
  activityLog: string
  contextUsage?: {
    tokens: number | null
    contextWindow: number
    percent: number | null
  }
  children: SubagentRunView[]
}

sessionId is the public continuation handle. episodeId identifies one subagent or subagent_resume lifecycle episode; multiple episodes can share one child sessionId. Nested child run metadata stays in structured run details; nested transcripts and final answers remain in their child sessions instead of being pasted into the parent model context.

Context usage comes from Pi's AgentSession.getContextUsage(). If Pi reports unknown usage, the progress text shows ? ctx; if usage is unavailable, the segment omits context usage. No custom TUI renderer is required for correctness.

Errors and limits

• Tool errors are thrown from execute(), which Pi records as failed tool results.
• Parent abort signals are forwarded to the child session. If a child session already exists, the durable status is aborted and the model-visible error text includes the Subagent session ID and examples for subagent_resume.
• Non-abort child failures after a trusted child session exists stay durable failed; the error text includes the public session ID only as a cautious “may be resumable” handle. Preflight and lookup failures before a trusted child session exists do not invent a continuation handle.
• Requested and recorded models are checked before the child is prompted. If a model is unavailable or unauthenticated, or Pi reports that it would fall back, the run fails instead of silently using a substitute.
• Requested thinking levels are validated against the resolved model before child artifacts are created. Unsupported levels fail with the supported list instead of silently clamping to a neighboring level.
• pi-submarine's wrapper text does not add session-file paths, activity-log paths, stack traces, child transcripts, or the Markdown activity log to model-visible success, interruption, or recovery text. The original provider or extension error message is preserved and may contain its own details.
• Manifest and activity-log append failures are logged and do not fail an otherwise successful child episode. Continuation needs the current-root manifest start record, so resume is not guaranteed after a degraded manifest write.
• In one Pi process, pi-submarine rejects concurrent attempts to append to the same child session, including subagent_resume while the original subagent is still active. This is not a cross-process lock.
• Nested subagents share the Node.js event loop and Pi extension runtime. Nesting deeper than 4 is rejected to stop accidental circular delegation.
• pi-submarine does not add a wall-clock timeout around Pi's session.prompt().
• Forked children start from the current branch and may see the current parent turn. Phrase fork tasks so parent-only final-answer markers do not conflict with what the child should produce.

Install

pi install npm:pi-submarine

Requires Pi 0.79.1 or newer. The package manifest registers ./src/index.ts, which Pi loads through its TypeScript extension loader. The npm package contains src/, README.md, and npm's automatic package.json.

Development

For local development, load the extension directly:

pi -e ./src/index.ts

Run the checks with:

npm install
npm run typecheck
npm test
npm run build
npm run smoke:registration

The model-facing tool labels, descriptions, schema descriptions, guidelines, and prompt envelope helpers live in src/tool-prompts.ts. Keep that file, src/index.ts, and this README in sync when the tool contract changes.
