pi-workflow-engine

Programmable multi-agent workflows for the pi coding agent.

This is not just a way to run a prompt. It is a way to turn an agentic procedure into code: scope the task, fork isolated subagents, fan out across review lenses, validate every handoff with schemas, verify candidate findings, and synthesize one ranked result.

The built-in workflows are advisory: they inspect, fan out, verify, and report. They do not edit files. Start with /workflow code-review, or use the focused scouts for refactors, diagnosis, and performance.

Why workflows matter

The best agentic coding work is rarely a single chat turn. It is a repeatable loop of context gathering, delegated investigation, structured handoffs, verification, and synthesis.

pi-workflow-engine brings that shape to pi with static TypeScript workflows:

• Procedures, not prompts: write the workflow once, then invoke it with /workflow or let the host agent call the workflow tool.
• Isolated subagents: each agent() runs in its own in-memory pi session, so exploratory work does not pollute the main conversation.
• Parallel cognition: run many focused agents at once, with a shared concurrency cap so large workflows stay bounded.
• Typed handoffs: pass structured data between stages using typebox schemas instead of asking the model to emit parseable prose.
• Verifier stages: make verification part of the control flow, not an optional final instruction.
• Live progress: surface phases, agent status, counters, and lane items in the TUI while the run is still moving.

The result is closer to an executable review playbook than a chatbot shortcut.

Install

pi install git:github.com/timbrinded/pi-workflow-engine

Or from npm:

pi install npm:pi-workflow-engine

That's all. pi fetches the package and serves its core dependencies from its own bundle, so there is no clone, install, or build step. The package entrypoint is the canonical pi extension module at .pi/extensions/pi-workflow-engine/index.ts. Restart pi, or run /reload in an open session, then confirm it is registered:

pi list

Scope it to a single repo instead of globally. This writes to that repo's .pi/settings.json:

pi install git:github.com/timbrinded/pi-workflow-engine -l

Uninstall with:

pi remove git:github.com/timbrinded/pi-workflow-engine

Usage

For the complete installation, invocation, authoring, tuning, and troubleshooting guide, see USAGE.md.

In a pi session, from inside a git repo with changes:

/workflow code-review            # review the current branch or open PR
/workflow code-review HEAD~3     # review a ref range, target, or focus area
/workflow refactor-scout src/    # find safe refactor opportunities
/workflow diagnose "typecheck fails after the schema change"
/workflow perf-review "workflow startup latency"
/workflow code-review --inspect  # open the live workflow inspector

The host agent can also invoke the workflow tool mid-conversation. It accepts either a registered workflow name or a one-off inline workflow script:

Run the code-review workflow on this PR and use the result before deciding what to fix.

Opt into dynamic multi-agent orchestration with the literal dynamax token, or keep it sticky for the session:

dynamax inspect this bug with multiple focused agents
/dynamax on
/dynamax status
/dynamax off

dynamax is a permission signal for the host agent: once opted in, it may run an existing named workflow or author an inline workflow script through the workflow tool. In interactive mode, /workflow with no arguments also offers ✍ Author temporary one-shot workflow…; choose it, type a brief, and pi will ask the host agent to author/run a temporary inline workflow.

The advisory workflows inspect and report only; they do not edit files. They return the same shape: summary, ranked findings, evidence, impact, recommendations, and next steps.

Built-in workflows

• code-review: Reviews the current branch, open PR, ref range, or target. It looks for correctness bugs and cleanup issues, then independently verifies candidates before ranking them.
• refactor-scout: Looks for small, safe refactor opportunities: duplication, complexity, weak types, boundary leaks, dead code, and convention drift.
• diagnose: Investigates a symptom, failing command, or regression. It generates competing root-cause hypotheses, verifies them, and returns the most likely causes with next validation steps.
• perf-review: Reviews a slow path or workload for bottleneck hypotheses, measurement gaps, and safe optimization directions. It avoids claiming certainty when measurement evidence is missing.

The code-review workflow

The bundled review workflow is deliberately shaped like a serious review process:

1. Scope: detect the open PR or branch diff, list changed files, and read relevant project conventions.
2. Find: fan out across focused review lenses such as logic bugs, error paths, edge cases, simplification, and conventions.
3. Gate and dedupe: bound candidates to changed lines and collapse duplicate findings before spending verifier tokens.
4. Verify: send each survivor to an independent verifier that must confirm, mark plausible, or refute with evidence.
5. Synthesize: produce one ranked report with stats, verdicts, and concrete locations.

The review lenses live in .pi/extensions/pi-workflow-engine/workflows/code-review.ts. That is where your repo's real failure modes belong.

Authoring workflows

A workflow is a TypeScript module that exports meta plus a default async (api) => result. The injected api gives you the primitives:

Primitive	Behaviour
agent(prompt, { schema })	Runs a subagent in an isolated session. With a typebox schema, returns validated structured data; otherwise returns final text.
parallel(thunks)	Runs every thunk concurrently and waits for all results.
pipeline(items, ...stages)	Runs each item through all stages independently, with no barrier between stages.
phase(title) / log(msg)	Drives the live progress tree shown in the TUI and stderr breadcrumbs when headless.
progress(event)	Emits structured progress for richer workflow UI surfaces.

import { Type } from "typebox";
import type { WorkflowApi, WorkflowMeta } from "../src/types.ts";

export const meta: WorkflowMeta = {
  name: "my-workflow",
  description: "Find, verify, and summarize something important.",
};

const FindingSchema = Type.Object({
  summary: Type.String(),
  file: Type.String(),
  line: Type.Optional(Type.Number()),
});

export default async function run({ agent, parallel, phase }: WorkflowApi) {
  phase("Find");

  const findings = await parallel([
    () => agent("Find correctness bugs in the diff.", { schema: FindingSchema, thinkingLevel: "low" }),
    () => agent("Find error-handling bugs in the diff.", { schema: FindingSchema, thinkingLevel: "low" }),
  ]);

  phase("Synthesize");
  return agent(`Summarize these findings: ${JSON.stringify(findings)}`, { thinkingLevel: "medium" });
}

Inline workflow scripts use the same primitives, but are passed as a string to the workflow tool instead of being saved as files. A minimal inline workflow starts with export const meta and uses the injected Type object for schemas:

export const meta = {
  name: "inline-review",
  description: "One-off focused review workflow.",
};

export default async function run({ agent, parallel, phase, args }) {
  phase("Find");
  const Finding = Type.Object({ summary: Type.String() });
  const findings = await parallel([
    () => agent(`Find correctness issues: ${args}`, { schema: Finding, thinkingLevel: "low" }),
    () => agent(`Find edge cases: ${args}`, { schema: Finding, thinkingLevel: "low" }),
  ]);
  return { summary: JSON.stringify(findings) };
}

Inline v1 rules: no imports, no dynamic import(), pure-literal meta, schemas must use the injected Type value, and scripts run in-process with the extension's permissions. This v1 path is permissive rather than sandboxed.

Under the hood:

• Each agent() is an in-process pi AgentSession using createAgentSession and SessionManager.inMemory().
• Structured output is a terminating tool. The engine registers one tool whose parameters is your schema; pi validates the call and the engine captures the args. There is no JSON scraping.
• A single global semaphore caps concurrent agents, so parallel and pipeline can nest freely while every agent() call still respects the run cap.
• Three surfaces are registered: /workflow <name> [args] for direct use, /dynamax on|off|status for sticky orchestration opt-in, and a workflow tool for host-agent delegation by name or inline script.

Local development

Only needed if you want to add workflows, customise workflows, or contribute. Using the bundled workflows requires none of this.

git clone https://github.com/timbrinded/pi-workflow-engine
cd pi-workflow-engine
bun install
bun run typecheck
bun run test

The test suite is no-LLM and uses Bun's built-in bun test runner, not a third-party test framework.

Performance controls and benchmarks

The workflow engine is measurement-first: tune only after checking queue wait, local orchestration, discovery, and UI render costs on the machine where you run pi.

Runtime controls:

• PI_WORKFLOW_PERF=1 enables the internal per-run performance recorder used by the orchestration instrumentation.
• PI_WORKFLOW_CONCURRENCY=N sets the per-run agent semaphore cap. The default remains min(8, max(2, CPU count)).
• PI_WORKFLOW_PARALLEL_SUBMISSION_LIMIT=N limits how many parallel() thunks are submitted at once; this is separate from the running-agent semaphore cap.
• PI_WORKFLOW_LANE_ITEM_LIMIT=N caps retained progress lane items per lane; snapshots report how many older items are hidden.
• Slash commands can override selected controls per run: /workflow <name> --concurrency=N --parallel-limit=N ....

No-LLM benchmark scripts:

bun run bench:concurrency -- --items 200 --concurrency 8 --json
bun run bench:discovery -- --iterations 3 --json
bun run bench:startup -- --json
bun run bench:ui -- --agents 1000 --lane-items 1000 --json

Add --out to write machine-local JSON under .artifacts/benchmarks/. These timings are advisory, not portable thresholds.

Guardrails:

• Do not pool or reuse subagent sessions until agent.create_session_ms is proven material and isolation semantics are reviewed.
• Do not lazy-load guaranteed built-in workflow modules until pi/jiti bundled typebox identity is proven for that path.
• Do not raise the default concurrency without queue-wait versus run-time evidence.

Load your working copy through the package manifest without installing it. This is ephemeral and exercises the same .pi/extensions/pi-workflow-engine/index.ts entrypoint that installed packages use:

pi -e .

This repo also includes .pi/settings.json for project-local auto-discovery. If you also have the global package installed, pi may report duplicate /workflow or workflow tool diagnostics; remove one source or force pi to ignore discovered extensions and load this working copy instead:

pi -ne -e .

Add a built-in workflow by creating .pi/extensions/pi-workflow-engine/workflows/<name>.ts, importing it in .pi/extensions/pi-workflow-engine/src/workflows.ts, and adding it to BUILTIN_WORKFLOWS. Statically imported workflows share pi's bundled typebox, which guarantees schema validation. Files in .pi/extensions/pi-workflow-engine/workflows/ and ~/.pi/agent/workflows/ are also discovered dynamically at runtime on a best-effort basis.

Keep guaranteed built-ins statically imported. Optimize cold startup at the extension entrypoint or discovery boundary first; do not lazy-load built-in workflow modules unless a test proves pi/jiti preserves the same bundled typebox identity for dynamically imported built-ins.

Tune the built-in review workflow by editing the ANGLES array in .pi/extensions/pi-workflow-engine/workflows/code-review.ts. Tune model, thinkingLevel, and tools per agent() call, and use PI_WORKFLOW_CONCURRENCY or /workflow <name> --concurrency=N for measured per-run concurrency experiments.

Layout

.pi/
  settings.json                         project-local pi resource settings
  extensions/pi-workflow-engine/
    index.ts                            canonical extension entry; registers the command and tool
    src/
      types.ts                          WorkflowApi / WorkflowModule contracts
      agent-runner.ts                   createAgentSession + terminating-tool schema bridge
      concurrency.ts                    Semaphore, parallel(), pipeline()
      engine.ts                         runWorkflow(); binds primitives to one run
      progress.ts                       live phase/agent tree via ctx.ui.setWidget
      discovery.ts                      static registry + best-effort drop-in loading
      workflows.ts                      statically registered built-in workflows
    workflows/
      code-review.ts                    scope -> find -> verify -> synthesize
      refactor-scout.ts                 advisory refactor opportunities
      diagnose.ts                       advisory bug diagnosis
      perf-review.ts                    advisory performance investigation

License

MIT. See LICENSE.
